信息

信息论奠基人香农（Shannon）认为“信息是用来消除随机不确定性的东西”，信息量用来量化消除的不确定的多少。事件发生的概率越低，那么该事件发生的信息量就越高

一个发生的事件x的信息量为

h(x) = – log_2{(P(x))}

概率越小，信息量就越大。

信息熵是所有可能发生事件的信息量的期望值

$$H(X) = – \sum_{x \in X}{p(x)  log_2(p(x))}$$

python代码中，data的最后一列是分类的情况，calcShannonEntropy函数用来计算信息熵。

#data : list of [f1 f2 f3 label]
def calcShannonEntropy(data):
    m = len(data)
    dic = {}
    for v in data:
        label = v[-1]
        if label not in dic.keys():
            dic[label] = 0
        dic[label] += 1
    shannonEntropy = 0.0
    for label in dic:
        p = dic[label] / float(m)
        shannonEntropy -= p * log(p, 2)
    return shannonEntropy

splitData用于选取第axis维度等于value的向量，同时在向量中去掉axis这一维度

def splitData(data, axis, value):
    ret = []
    for v in data:
        if v[axis] == value:
            t = v[:axis]
            t.extend(v[axis+1:])
            ret.append(t)
    return ret


chooseBestFeatureToSplit函数中，分别对每个特征计算选择后的信息熵，选择最好的特征。

def chooseBestFeatureToSplit(data):
    n = len(data[0]) - 1
    bestFeature = 0
    bestShannonEntropy = calcShannonEntropy(data)
    for i in range(n):
        featureList = [v[i] for v in data]
        values = set(featureList)
        shannonEntropy = 0.0
        for value in values:
            subdata = splitData(data, i, value)
            p = len(subdata) / float(len(data))
            shannonEntropy += p * calcShannonEntropy(subdata)
        if shannonEntropy < bestShannonEntropy:
            bestFeature = i
            bestShannonEntropy = shannonEntropy
    return bestFeature

createTree

def majorityCount(classList):
    dic = {}
    for v in classList:
        if v not in dic.keys():
            dic[v] = 0
        dic[v] += 1
    sortedDic = sorted(dic.items(),
                       key = operator.itemgetter(1),
                       reverse=True)
    return sortedDic[0][0]

def createTree(data, labels):
    classList = [a[-1] for a in data]
    if classList.count(classList[0]) == len(classList):
        return classList[0]
    if len(classList[0]) == 1:
        return majorityCount(classList)

    bestFeature = chooseBestFeatureToSplit(data)
    bestFeatureLabel = labels[bestFeature]
    tree = {bestFeatureLabel:{}}
    del(labels[bestFeature])
    features = set([a[bestFeature] for a in data])
    for feature in features:
        subLabels = labels[:]
        tree[bestFeatureLabel][feature] = createTree(
                splitData(data, bestFeature, feature),subLabels)
    return tree


def classify(inputTree, featureLabels, testVec):
    firstStr = list(inputTree.keys())[0]
    subTree = inputTree[firstStr]
    featIndex = featureLabels.index(firstStr)
    for key in subTree.keys():
        if testVec[featIndex] == key:
            if (type(subTree[key]).__name__ == 'dict'):
                classLabel = classify(subTree, featureLabels, testVec)
            else:
                classLabel = subTree[key]
    return classLabel
